BPT E 30 (24) C

Order no. 575203

B.PROTHERM E 30 (24) x 1/1 cooled
B.PROTHERM E food transport container 1/1, convection-cooled,
made of corrosion-resistant steel, with hinged door, mobile.
30 support ledges: 24 x 1/1 and 6 x 1/2.
Space between ledges: 38.3 mm
Temperature range adjustable between +2 °C and +10 °C.
Refrigerant: propane R290
Mains frequency: 50/60 Hz

Base model: 386609

BPT E 30 (24) C

Attributes Advantages

Back to overview

Attributes

Exterior dimensions width	821 mm
Exterior dimension height	1.532 mm
Exterior dimensions length	590 mm
Exterior dimension unit	MM
Rated voltage	220-240 V
Rated power	0.27 kW
Emissions	The workplace-specific noise level for the unit is less than 70 dB(A)
Weight	100 kg
Heating and cooling technology	Active convection cooling
Hygiene type	HS
Insulating material	PUR foam panels, CFC-free
Refrigerating capacity	0.35 kW at t0= -10 °C and tu= +32 °C
Refrigerant	Propan R290
Capacity	12 x GN 1/1-65
Climate class	4
Mains frequency	50/60 Hz
MatNo. (18 digits)	000000000000575203
Protection type	IPX5
No. of ledges	30
Space between ledges	38,3 mm
Temp. range (free text)	<p>Can be regulated down to the degree from +2 °C to +10 °C at an ambient temperature between +15 °C and +38 °C</p>
Temperature resistance	to
Ambient temperature – operation	15 °C to 38 °C
Ambient temperature – operation from	15 °C
Ambient temperature – operation to	38 °C
Type	gekühlt
Material(s)	Stainless Steel 1.4301 Polyethylene (PE)
Volume	0.742
Volume unit (capacity)	M3
Heat emission sensitive	192 W

Downloads

Brochures

BPROTHERM_Edelstahl_Broschüre_de-3.pdf 4 MB

BPROTHERM_Edelstahl_Broschüre_en-3.pdf 4 MB

BPROTHERM_Edelstahl_Broschüre_es-3.pdf 4 MB

BPROTHERM_Edelstahl_Broschüre_fr.pdf 4 MB

BPROTHERM_Edelstahl_Broschüre_nl-3.pdf 4 MB

BPROTHERM_Edelstahl_Broschüre_cz.pdf 4 MB

Revit

Advantages

Extremely efficient, flexible use of interior thanks to uniform space between ledges of 38.3 mm
Active convection cooling with sophisticated airflow concept for rapid, uniform cooling distribution
12 different body colours, perfect for logistical coding and customisation
Environmentally friendly refrigerant propane R290 - natural, resource-saving and future-proof
Connectivity for digital hygiene, temperature and process management. You can digitalise all processes using the optionally integrable sensors to ensure safety and save time.
